G-Rib Metal Panel

G-Rib Metal Panel

Regular price
Sale price
Regular price
Sold out
Unit price

G-Rib is available with our 40-Year Warranty and has a minimum thickness of .0153 before paint and an AZ50 Galvalume® substrate. It also carries 20 Year Perforation Warranty on a Galvalume® steel substrate. All colors have an Energy Star® rating and comes with a UL® 2218 Class 4 impact rating and a UL® 790 fire rating. G-Rib is offered in a 80,000 PSI maximum hardness to allow for the intricate bends of this panel.

View Color Chart Here

View Crinkle Color Chart Here

 G-Rib Panel Features

  • Available in 29 & 26 gauge
  • 22 flat colors & 15 textured (29 gauge only) colors
  • 36″ coverage
  • 9″ rib spacing
  • 3/4″ rib height
  • Cut to the 1/4″ inch
  • CERAM-A-STAR 1050 40-year paint warranty
  • AZ-50 Substrate for Painted Panels or AZ-55 Substrate for Galvalume Non-Painted Panels
  • Anti-siphon leg ensures a weather tight seal

       View G-Rib Trim Options Here

      G-Rib Spec Sheet

      Sherwin-Williams Weather XL, Weather XL Crinkle Limited Warranty
